Beta Port-P Pressure Module
|
Item Number: BetaPort-P
Manufacturer: Beta Calibrators (Martel Electronics)
Manufacturer Part No: BetaPort-P
Personalization
* denotes required field
BetaGauge II - BetaFLEX - Martel Pressure Modules*
|
Beta Port P Pressure Modules
BETA offers 24 standard pressure modules, covering gauge, vacuum, absolute, compound,and differential measurements. All modules are directly compatible with the BetaGauge II and the BetaFLEX. With the Model BPPA-100 BETA Port Pressure Adapter, the modules are fully compatible with the BETA 950, BETA 850, Martel MC-1200, Martel MC-1000, and Martel M2001. Pressure ranges may be displayed in any of 13 user-selectable units. Water density correction factors of 4 C, 20 C, or 60 F can be selected for either water column unit. The choice of pressure unit may be restricted by limitations on resolution of the instrument display.
Features:
- 29 standard ranges
- Gauge, vacuum, absolute, compound and differential measurements from inches H2O to 10,000 psi
- Accuracy specified over 15 C to 35 C range
- Isolated and non-isolated measurements, range dependant
- .025% full scale accuracy
|
|
Available Pressure Ranges:
|
Gauge
|
Vacuum
|
Absolute
|
Differential**
|
|
|
0 to -5 PSIG
|
0-15 PSIA
|
|
|
0-10 PSIG
0-30 PSIG
|
0 to -15 PSIG
|
0-30 PSIA
|
|
|
0-50 PSIG
0-100 PSIG
|
|
0-50 PSIA
|
|
|
0-150 PSIG
0-300 PSIG
|
|
0-100 PSIA
|
|
|
0-1000 PSIG
0-1500 PSIG
|
|
0-300 PSIA
|
|
|
0-3000 PSIG
0-5000 PSIG
|
|
|
|
All ranges come standard with eight engineering units, readout selection, keypad
selectable by the operator (in H2O, inHg, PSI, kPA, mmHg, mBar, cmH2O, Bars,
plus a user defined scale).
**Maximum static pressure, 200 psig
Specifications:


|
