SI Pressure TP1 - Precision Pressure & Vacuum
Calibration Pump

The TP1 is a precision pneumatic calibration pump.
The TP1 Pressure Test System has been introduced to complement
an already extensive range of calibration products and can be used for
calibration checks on pressure transmitters, pressure switches, indicators,
recorders and controllers. It makes an ideal low cost calibrator when
combined with a digital or analog test gauge.

Calibration checks can be carried out simply by temporarily shutting
off line pressure, selecting the digital indicator or test gauge required and
connecting the instrument via the flexible hose and swivel adaptor to the
pressure measuring instrument to be checked. The range of adaptors enables
connection to most gauge threads. TP1 can be used as a portable Pressure
Comparator in conjunction with various pressure indicating devices. This
precision unit now includes an adjustable over pressure protection system
as a standard feature.

Features:

• Dual Source for Pressure and Vacuum
• Fully Portable, Hand Operated Kit
• Fine Pressure Adjustment and Vent Valves
• TP1 Generates 360 PSI or -24" Hg Vacuum
• Adjustable Stroke To Provide Over Pressure Protection
• 1/4" NPT Ports
• Compact Size, 8.6" x 4" x 2.5", 1 Lbs 2 Ozs.

Discontinued, SEE SI Pressure TP1-40 Pump
